Digital Multimeter
SKU: 55142
MAX. 5999 DISPLAY COUNTS
Model no: DL334303
Brand: DELI TOOLS
ALU: 6974173011337
Color: BLACK/RED
Deli Tools – Digital Multimeter
Brand: Deli Tools
Model: DL334303
Color: Black/Red
Tool Category: Professional
Display: 3 5/6 digits LCD, max. 5999 counts
Altitude: <2000m
Pollution Level: 2
Max. Input DC Voltage: 1000V
Max. Input AC Voltage: 750V
Max. Input AC/DC Current: 10A
Security Class: CAT IV 600V. CAT III 1000V
Sampling Rate: About 3 times/sec
Battery: 1.5V AA battery
Main Functions: 9
- DC/AC Voltage measurement
- DC/AC Voltage mV measurement
- Frequency/Duty measurement
- DC/AC Current measurement
- Resistance measurement
- Continuity measurement
- Diode measurement
- Capacitance measurement
- Temperature measurement
- NVC / Live test
Temperature coefficient: 0.1x accuracy/°C (<18°C or >28°C)
Working Environment Temperature / Relative Humidity: 0°C to 40°C (<80% RH, <10°C non-condensing)
Storage Environment Temperature / Relative Humidity: -10°C to 60°C (<70% RH, remove the battery)
Material: Plastic
Product Dimension (W x D x H): 90 x 53 x 190mm (3.5” x 2.1” x 7.5”)
Features:
- Auto-power off.
- Flashlight lighting.
- LED indication for sockets.
- Sampling rate: 3 times/second.
- The maximum product reading is 5999.
- Safe and reliable, with a safety level of CAT III 1000V.
- High voltage warning: when high voltage is detected, the screen backlit in orange light.
- This product is a 3 5/6 digital multimeter, it can be used to measure AC/DC voltage, AC/DC electricity, electrical resistance, capacitance, frequency, duty cycle, temperature and more.
Package Contents:
Digital Multimeter – x1
AA 1.5V Battery – x2
Test Lead – x2
K Thermocouple – x2
User Manual – x1
Click here for User Manual
