Basic installation does NOT INCLUDE: AC removal, Casing works, Extending pipes  and any kind of carpentry or electrical works.

All above services can be provided at additional charges. To avoid any inconvenience, Asters can conduct a survey with a detailed quote prior to the installation.



Specification


Aux – Air Conditioner (9000BTU)

Brand: Aux

Model: MASDC09QGR1-Q-Smart

Capacity: 9000BTU

Color: White

Cooling:

    • Rated Capacity: 2640W (600 – 3200W)
    • Rated Power Consumption: 820W (400 – 1400W)
    • Rated Running Current: 3.9A (1.7 – 6.1A)

Max. Input Power: 1600W

Max. Input Current: 8A

EER Cooling: 3.22 W/W

EU Energy Rating: A+++

Power Supply Source: 220-240V – 1PH – 50Hz

Refrigerant: R32

Refrigerant charged: 400g

Max. Discharge Pressure: 4.3 Mpa

Max. Suction Pressure: 2.5 Mpa

Air Flow Volume: 540 m3/h

Warranty: 1 Year Warranty plus 5 Years Compressor Warranty



Indoor Unit:

Indoor Noise Level: 40 dB(A)

Evaporator:

    • Rows: 2
    • Tube pitch: 20.5
    • Tube Material: screws inside
    • Tube Thickness: 0.25mm
    • Tube Quantity: 10
    • Fin Material: hydrophilic foil
    • Fin Type: window
    • Fin Thickness: 0.095mm
    • Fin spacing: 1.3mm

Fan System:

    • Type: Crossflow
    • Material: AS

Connect pipe (length): 3m

Stop Valve:

    • Liquid valve: 0.25 (1/4”)
    • Gas valve: 0.375 (3/8”)



Outdoor Unit:

Outdoor Noise Level: 51 dB(A)

Type: Rotary

Fan:

    • Type: Axis flow
    • Vane Number: 3
    • Blade Material: AS

Motor: D-20-10A

Condenser:

    • Row: 1
    • Tube Material: screws inside
    • Tube Quantity: 11
    • Fin Material: hydrophilic foil
    • Fin Type: window
    • Fin spacing: 1.3mm



Dimension & Weight:

Net dimensions (W x H x D):

    • Indoor: 708 x 282 x 193mm
    • Outdoor: 703 x 455 x 233mm

Packing dimensions (W x H x D):

    • Indoor: 765 x 351 x 269mm
    • Outdoor: 760 x 510 x 305mm

Net weight:

    • Indoor: 7kg
    • Outdoor: 17kg

Gross weight

    • Indoor: 10kg
    • Outdoor: 20.5kg



Click here for User Manual
